Background on AMD EPYC 9004 CPUs
AMD's EYPC line of processors are built for demanding server workloads. Each of these CPUs is a whole system on a chip (SOC), which means they have an I/O die built-in, so there is no need for a separate chipset on the motherboard to provide PCI-Express, SATA, etc. The EPYC 9004 Series also supports 12 DDR5 channels, providing a huge amount of memory bandwidth to keep up to 96 cores fed with data.
Model: AMD 100-000000796
Specifications
| Product Line | EPYC |
| Code Name | Genoa |
| Socket | SP5 |
| Process | 5 nm |
| Total Number of Cores | 16 |
| Total Number of Threads | 32 |
| Base Clock Speed | 4.1 GHz |
| Simultaneous Multi-Threading | Yes |
| Max. Turbo Boost | 4.4 GHz |
| All-Core Turbo Boost | 4.15 GHz |
| Thermal Output | 320 W |
| PCI-E Lanes | 128 |
| Socket Count | 1P/2P |
Cache | |
| L3 | 256MB |
Memory Specification | |
| Memory Type | DDR5 |
| Maximum Frequency | 4800 |
| ECC Support | Yes |
| Registered Support | Yes |
