Model: Intel CM8071505094011
Specifications
| Product Line | Core i9 |
| Code Name | Raptor Lake |
| Socket | 1700 |
| Process | 10 nm |
| Total Number of Threads | 32 |
| Total Number of Cores | 24 |
| Number of Efficient Cores | 16 |
| Base Clock Speed | 3.0 GHz |
| Hyperthreading | Yes |
| Turbo Boost | Yes |
| Max. Turbo Boost | 5.8 GHz |
| Efficient Core Max Turbo Boost | 4.3 GHz |
| All-Core Turbo Boost | 5.5 GHz |
| Long Duration Power Limit | 125 W |
| Short Duration Power Limit | 253 W |
| PCI-E Lanes | 24 |
| Max Temperature | 100 C |
Cache | |
| Smart Cache | 36MB |
Onboard Graphics | |
| Processor Type | UHD Graphics 770 |
| Core Speed | 1.65 MHz |
| DirectX Version | 12 |
| Cores on Die | 32 |
| # of Displays Supported | 3 |
Memory Specification | |
| Memory Type | DDR5 |
| Maximum Frequency | 5600 |
| Registered Support | No |
Advanced Technologies | |
| vPro | Yes |
| Trusted Execution Technology | Yes |
